Treuil Warn XD 9000 12 V. 4,1T.

Description

Part Number: 88500 (12V, CE, International sales only)
Rated line pull: (4080 kgs.) single-line
Motor: Series Wound: 12V 4.6 hp
Electrical controls: Contactor
Remote Control: Remote switch, (3.7m) lead
Geartrain: 3-Stage Planetary
Gear ratio: 156:1
Clutch (freespooling): Sliding Ring Gear
Brake: Automatic Direct Drive Cone
Drum diameter/Length: (6.4cm/23cm)
Weight: (35kgs.)
Wire rope:  (30m, diam. 8mm)
Fairlead: Roller
Recommended Battery: 650 CCA minimum for winching
Battery leads: 2 gauge, 72 in (1.83m)
Finish: Argent Gray Powder Coat
12V DC PERFORMANCE SPECS
Line Pull
Lbs.(Kgs.)
Line Speed
FT./min(M/min.)
Motor
Current
Pull by layer
layer/Lbs(Kgs.)
0 38(11.6) 70 amps 1/9000(4082)
2000(910) 14.4(4.39) 180 amps 2/8190(3715)
4000(1810) 11(3.35) 255 amps 3/7500(3402)
6000(2720) 8.67(2.64) 330 amps 4/7010(3180)
8000(3630) 6.88(2.10) 415 amps
9000(4080) 6.38(1.94) 460 amps

Caractéristiques

Marque Compatible toutes marques
Modèle TOUS MODELES
Treuil Warn XD 9000 12 V. ; 555mm L. x 160mm D. x 193mm H.) ; traction de 4.080 kgs ; pour le Ford ranger à partir de '2012 : il y a 1 découpe à faire dans le pare-chocs
